FACE MILLING CUTTER

FACE MILLING CUTTER

Specification
Recommended

※ FACE MILLING CUTTER Specification ※

FACE MILLING CUTTER
Outside diameter	50	60	75	100
Thickness	50	40	50	50
	60	50	60	75
		60	75	100
				125
Teeth number	12	14	14	16
Hole diameter		25.4	1"
Special specifications are available upon request Welded tungsten material is available

※ FACE MILLING CUTTER Recommended ※

	Workpiece Mat'l	Casting Steel	Carbon Steel	Special Steel Tool Steel Stainless Steel Heat-resistant Steel	Forging Cast Iron Forging Cast Steel	Copper and Copper Alloy	Aluminum Alloy
Cutting Rate		20~25 m/min	20~25 m/min	15~20 m/min	22~25 m/min	40~120 m/min	200~300 m/min
D(mm) Outside Dia.(D)	75	0.20~0.29	0.11~0.17	0.09~0.12	0.15~0.18	0.07~0.18	0.06~0.15
D(mm) Outside Dia.(D)	90	0.17~0.24	0.09~0.13	0.08~0.10	0.13~0.14	0.05~0.15	0.05~0.12

Specifications and design characteristics are subject to change without prior notice.
